Understanding planes and axes of movement is essential for analysing how the human body moves during physical activity. These concepts offer a structured approach to describing the direction and orientation of movement, particularly within joint actions and whole-body biomechanics. Movements occur in three anatomical planes—sagittal, frontal, and transverse—and each movement occurs around a corresponding axis of rotation. These relationships help explain how complex actions, such as running, jumping, or throwing, are made possible through the coordinated function of joints and muscles.

The sagittal plane divides the body into two halves, left and right. Movements that occur in this plane involve flexion and extension, such as bending the knee, performing a bicep curl, or running forwards. These movements occur around the transverse axis, which runs horizontally from left to right. The sagittal plane is most relevant in analysing forward or backwards motion, commonly seen in activities like cycling or sprinting.

The frontal plane divides the body into front and back sections. Movements in this plane include abduction and adduction—for example, raising the arms or legs sideways away from the body or bringing them back towards the midline. These movements occur around the anteroposterior axis, which runs horizontally from front to back. The frontal plane is helpful for analysing lateral movements such as side lunges, cartwheels, or defending in team sports.

The transverse plane divides the body into upper and lower halves. It involves rotational movements such as medial and lateral rotation, pronation and supination, or turning the head side to side. These actions occur around the longitudinal axis, which runs vertically through the body from head to toe. This plane is critical in analysing movements like throwing, swinging a bat, or performing a spin in dance or gymnastics.

Every movement in sport or daily activity can be broken down into these planes and axes. For example, a football kick involves hip flexion in the sagittal plane around the transverse axis. In contrast, a tennis forehand involves trunk rotation in the transverse plane around the longitudinal axis. Understanding this framework enables more precise analysis of technique, identification of strengths and imbalances, and improved movement efficiency.

In biomechanics and sports performance, identifying the plane and axis of movement enables coaches, athletes, and therapists to describe motion accurately, plan training effectively, and prevent injuries. Whether analysing movement for performance enhancement or recovery, this system provides a foundational language for understanding how the body operates in three-dimensional space.
